20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion

MOQ : 1 Piece

Price : US$3000-3500

Place of Origin : Xinxiang

Brand Name : BETTER

Packaging Details : Single Package: Dimensions 300×200×100 cm; Gross Weight 1000 kg; Quantity per Package 1 unit.

Delivery Time : 15-30 days

Payment Terms : L/C,T/T

Supply Ability : 50 Sets/Month

Model Number : BXC

Product Name : Heavy Load Transport Cart

Usage : Heavy Duty Material Transportation

Application : Steel Industry, Factory, Warehouse, Port

Material : Steel

Load Capacity : 1-1500 Tons

Control Mode : Pendant/Remote/PLC Control

Control Way : Hand Pendant/Remote Controller

Customized Function : Anti-Explosion, Heat-Resistant, Lifting, Dumpling

Transport Package : Other

Trademark : BETTER

Origin : China

HS Code : 84289090

Production Capacity : 5000/Years

Contact Now

20t Aluminum Coil Transport Transportation with Lifting Platform
Product Description

Introduction of Hydraulic Lifting Trolley

The line of better Hydraulic Lifting Trolley includes both "scissor" and "direct lift" designs to meet a wide range of handling requirements of our clients.
As with all better products, our Hydraulic Lifting Trolley are designed to meet the specific requirements of each application. The height of our scissor lift tables ranges from 8" to 24" depending on the size and load capacity requirements. And depending of the lift requirements of the unit, the table would be equipped with a single, double or triple arm arrangement.
20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion
Parameters
Model BXC-2t BXC-5t BXC-10t BXC-16t BXC-20t BXC-25t BXC-30t BXC-40t BXC-50t BXC-63t BXC-80t BXC-100t BXC-150t
Rated Load(t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size (mm) Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Height(H) 450 500 500 550 550 600 600 650 650 700 800 900 1200
Wheel Base(mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Diameter (mm) 270 270 300 350 350 400 400 500 500 600 600 600 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Total Power(kw) 2 3 2.2 2.2 2.2 3 3.5 4 5 6.3 8 10 15
Battery Capacity(Ah) 150 180 180 200 220 220 260 300 330 400 400 440 600
Battery Voltage(V) 48 48 48 48 48 48 48 48 48 48 72 72 72
Running Time When Full Load 4.32 5.4 4.8 4.3 4 4 3.5 3.6 3.3 3 3.6 3.2 2.9
Running Distance for One Charge(km) 6.5 8.1 7.2 5.1 4.8 4.8 4.2 4.3 4 3.6 4.3 3.8 3.2
Max Wheel Load(KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100 QU100
Application

Application of Hydraulic Lifting Trolley

better Hydraulic Lifting Trolley are operating in many shipping lines, stevedores, concrete manufacturers, foundries, steel mills, etc. We have supplied Hybrid Transfer Cart in the world for moving heavy duty materials and equipments inside and outside the plant by electric traction and driving long distances. And also Hydraulic Lifting Trolley are mainly used to solve manoeuvrability problems in tight spaces.
20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion
20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion

Customized of Hydraulic Lifting Trolley
The material handling vehicle can be designed to travel on steel rail bars or they can be operated directly on the floor of your facility
1Ton to 300 Ton capacity range
Push and Pull operation or completely motorized
Full steer-ability or controlled direction of motion
Custom shaped table size to suit your application
Lifting fixtures available for simple transportation
Fully automated controls, wireless control system, or a fixed pendant

Other Products
Henan better Handling Equipment Co., Ltd. is specializing in the Design and Manufacture of transport system to solve every material handling requirement. Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Scissor Lift Tables, Turntables and many other specialty items. We design our special transfer cars for all kind of industries. We can manufacture them according to clients' specifications. For example, we can prepare them to be used in rails, with autonomous batteries or for special applications.
20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion

Customer Visit & Our Factory
20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion
20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion


Packaging & Shipping
20t Aluminum Coil Transfer Cart With Lifting Platform Anti Explosion
FAQ

Q & A


1.What Product Handling Applications Use Transfer Carts?
1. Coils (V-Groove deck)
2. Tanks (size/stability for uniformly distributed loads)
3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
4. Sub-Assembly shuttle from one line to another line
5. Maintenance cart for motors and pumps
6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
7. Material shuttle for steel tubing (flat decking with guard rails)
8. Elevating platform for assembly process (integrated screw-jack table)
9. Sand casting (flat decking)
2. How can Transfer Carts be customized?
Please tell us:
What load or product will be transferred onto the cart?
What is the weight of the heaviest lift or load?
What are the dimensions? (Length; Width ; Height)
What is the trip time and frequency? (# of Trips per , Shifts per day:)
What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc)
What is the distance to travel?
Other relevant information or using condition.
